RecLED 487x237mm
Up to 198lm/W - rectangular 2500lm-class modules
Description

RecLED 487x237mm

  • MST built-in constant-current rectangular LED modules, 487x237mm, nominal 2500lm/54V designation.
  • CRI 80 CJ G4 and CN G3 at 3000K or 4000K; other CCT and CRI on request.
  • CJ G4 at 4000K: 270mA, 48V forward voltage, 13W and 2587lm, up to 198lm/W. The 3000K version delivers 2487lm at 190lm/W. Current range 40-1000mA.
  • CN G3 at 4000K: 280mA, 49V, 14W and 2602lm, up to 190lm/W. The 3000K version delivers 2466lm at 180lm/W. Current range 40-800mA.
  • Follow the supplied driver and wiring diagrams; modules connected in parallel must share the same V-code group to prevent uneven luminous intensity.
  • 120° beam angle, 3 SDCM initial colour consistency and RG1 unlimited photobiological safety. Rated performance temperature 65°C; maximum safe case temperature 85°C. CE, ENEC, RoHS and REACH compliant.
  • Re-workable push-in terminals accept 0.2-0.75mm² solid or flexible wires, with an 8-9mm strip length.
  • No standalone IP rating; suitable protection must be provided by the luminaire.
  • CJ G4, 3000K / 4000K ordering codes: 1010 147 61746; 1010 147 61846.
  • CN G3, 3000K / 4000K ordering codes: 1010 147 61546; 1010 147 61646.
