PY‑25‑V‑XP
  • PY‑25‑V‑XP
  • PY‑25‑V‑XP
  • PY‑25‑V‑XP
  • PY‑25‑V‑XP
Documents joints
Téléchargement
DATASHEET

PY-25-V-XP.pdf.pdf

Téléchargement (1.33M)

PY‑25‑V‑XP

PY‑25‑V‑XP
IP68 screw connector 2/3/4/5pins
Description

PY‑25‑V‑XP

  • ● IP68 screw connector for waterproof outdoor and industrial wiring
  • ● Available in 2, 3, 4 and 5‑pin versions
  • ● Screw‑terminal wiring for firm electrical contact
  • ● PA66 UL94 V‑0 housing with silicone rubber seal
  • ● Rated 32A / 450V
  • ● Supports wire section up to 4mm²
  • ● Accepts cable diameters 5–9mm, 9–12mm and 10–14mm
  • ● Stripping length 8–10mm
  • ● Operating temperature −40°C to +105°C
  • ● Ideal for lighting systems, power distribution and harsh environments
