SC20W150-500CG4-G-NX

156390
Description

156390

SC20W150-500CG4-G-NX - 156390 - NEXIVO by KGP GMBH - Driver LED - Courant constant - Courant de sortie 150-500 mA - Puissance de sortie 3-20 W - Tension de sortie 20-40 V - Tension d’entrée 220-240 VAC - PF ≥ 0,92 - THD ≤ 20% - Rendement ≥ 86% - Isolation - Class II - IP20 - Independent - Dimensions 128 x 30,8 x 43 mm - Durée de vie 50000 h - Garantie 5 ans

Specific References a

KGP EQUIVALENT CODE 145551
LAS CODE 156390
MANUFACTURER NEXIVO by KGP Electronics GmbH
Dimming ON OFF
Output Type Constant Current
Min Output Current mA 150
Min Input Voltage V 20
Max Output Voltage in V 500
Max Output Voltage in V 40
Remote or Built In Independent
IP RATING IP20
How To Program the Current? DIP switches
Length 128
Width 30.8
Heigth 43
KGP EQUIVALENT MODEL SC20W150-500CG4-G
